PREVIEWCREATIONTRANSPARENCY (AutoCAD 2012)Ĭontrols the transparency of preview generated when using SURFBLEND, SURFPATCH, SURFFILLET, CHAMFEREDGE, FILLETEDGE, and the LOFT commandĬETRANSPARENCY. HPTRANSPARENCY (AutoCAD 2011) Sets the default transparency for new hatches and fills. the hatch entitities (when listed) should report transparency set "Bylayer" It is recommended that the transparency setting in the layer manager is used to control visibility of transparent hatches. The default setting for the transparency value for layers and objects is 0, the maximum value is 90.
You can set opacity by layer, by block, or individually for an object. Transparency is controlled in the properties of selected objects and can also be set to a default value for new objects. Making it easy to create transparent hatches. In AutoCAD, you can adjust the transparency value of any type of object including text, lines, images and hatching. All of the files listed in the following table are in ASCII format, which means you can view and edit them with a text editor, such as Notepad.Since AutoCAD 2011 there has been a transparency property that allows you to apply transparency to objects & layers in the same way you apply colours, linetypes, and lineweights. You can import AutoCAD customization files and export IntelliCAD formats using the Customize dialog box. You can continue using aliases and menu files from AutoCAD by importing the appropriate file. Importing and exporting customization files You can select the entities to be changed using any entity-selection method. To change the properties of a single entity in the selection set, choose the entity from the list at the top of the Properties pane. In the Properties pane, changes that you make in the Layer, Color, Thickness, Lineweight, Linetype, Linetype Scale, and Print Style (if using named print style tables) fields affect all selected entities. IntelliCAD menu bar is not available by default and can easily be activate through a right mouse click on top of the IntelliCAD Ribbons. Users can use both the default Ribbon interface and the IntelliCAD dropdown menu. The available menu options depend on the experience level that is set at the IntelliCAD general options. In addition to command names, suggestions can include names of external commands, system variables, aliases, and LISP functions.Ĭommands can also be deployed from the IntelliCAD dropdown menu by choosing them from the available list of menu options. Simply select the desired command in the list. The suggested names appear in an AutoComplete window. When you type in the command bar, IntelliCAD suggests names of matching commands as you type.
#Autocad lisp line transparency software
Move or resize the command bar by dragging it.ĬMS IntelliCAD® also supports AutoCAD® software menus (MNU), dialog boxes (DCL), fonts (SHX), scripts (SCR), and symbol libraries, so you can easily transfer custom AutoCAD® software environments into IntelliCAD® and continue working in your favorite drafting environment. By default the command bar displays the three most recent lines of prompts, but you can extend the window to display more lines.
The command bar is a dockable window in which you type IntelliCAD commands and view prompts and other program messages. The toolbars and command bar can also be floated anywhere on the screen or docked to the edges of the main IntelliCAD window. For example, you can display and rearrange the toolbars, display the command bar, and enable the status bar. Select AutoCAD® software commands from the pull-down menus and toolbar icons, or type AutoCAD® software command syntax at the optional command line prompt - whichever best fits your work style. You can work with the CMS IntelliCAD window and its elements in a variety of ways. CMS IntelliCAD® supports hundreds of AutoCAD® software commands.
